H76 single plate check valve
H76 single plate check valve
EXECUTIVE STANDARDS AND PERFORMANCE SPECIFICATIONS:
NOMINAL DIAMETER DN8-DN100、1/2"-12"
NOMINAL PRESSURE PN16、150LB
SHELL STRENGTH TEST PRESSURE PN2.4MPA
LOW PRESSURE AIR TIGHTNESS TEST PRESSURE 0.8MPA
APPLICABLE MEDIA WATER、OIL、GAS、NITRIC ACID、ACETIC ACID
DESIGN AND MANUFACTURING STANDARDS ANSI B16.34、GB/T-12224-2015
TEST STANDARD API598、GB/T13927-2008、EN12516-3
THREAD STANDARD G、BSP、BSPT、DIN259 、DIN2999、ISO228 、NPT 、PT 、ISO7/1



MATERIAL LIST OF MAIN ACCESSORIES:
VALVE BODY A216(WCB)、A351 CF8、CF8M、CF3M、321、2205
VALVE PLATE SUS304、SUS316 、SUS316L、SUS321、SUS2205
VALVE SEAT SUS304、SUS316、PTFE、RPTFE、M111、M1600、M1700、PPL
SCREW SUS304、SUS316



Product description:

Working principle: the check valve automatically opens and closes the valve disc depending on the flow of medium itself to prevent medium backflow.

Storage, maintenance, installation and use:

1. The valve shall be stored in a dry and ventilated room, and both ends of the valve channel shall be blocked.

2. Valves stored for a long time shall be inspected regularly to remove dirt. Pay special attention to the cleaning of the sealing surface to prevent damage to the sealing surface.

3. Before installation, carefully check whether the valve mark is consistent with the use requirements.

4. Check the inner cavity and sealing surface of the valve before installation. If there is dirt, wipe it with a cleaning cloth.

5. Before installation, the flow direction mark on the valve shall be consistent with the medium flow direction.

6. The lifting vertical disc check valve shall be installed on the vertical pipeline, and the lifting horizontal disc check valve and swing check valve shall be installed on the horizontal pipeline.

7. Pay attention to whether the valve has abnormal sound and vibration during use. In order to prevent water hammer effect in the pipeline, pay attention to the pressure fluctuation of pipeline medium.

K WOD Valve, SJFM brand, WOD brand,unique and advanced design concept of the product, combined with high-end and exquisite CNC processing technology, the processing size of each valve is strictly controlled within the tolerance range, and the processing size of all structural design and accessories selection is strictly in accordance with the industry front-end standards and 6S, CE, TS, ISO9001, ISO14000, ISO18000, API, GB and other standards. Make each valve practical, safe and long-life, and bring high utilization value to customers.
